7273PLK Heavy Duty Automatic Pattern Sewing Machine with Hot Knife Thread Cutting System for Slings, Belts, Harnesses and Ropes

Click here for DEMO video

$19,950.00, plus shipping

Special order this machine by calling 330 692 1418. Customer service will be happy to help and provide you with an estimated lead time.

Call us at: 330 692 1418 for more information, or to order

Description +

The large Barrel shuttle hook that has been specially designed for sewing very heavy materials and thick thread;
The special large bobbin capacity reduces the number of bobbin changes and offer high efficiency in sewing products using extra thick thread up to metric size 7* (=V415, T-400, 1300dx3);
The burning type automatic thread trimmer (heat cutter) is special designed for cutthing very thick Polyester sewing thread and Nylon sewing thread (without fringing). And the shorter-thread remaining mechanism trims the thread short and eliminates the trouble of manual thread nipping;
Standard equip with harness webbing clamp ( tailor made) for the production of height safety harness, fall protection equipment and lanyard products.
Rope bar-tacking clamp is available as option;;
The cold automatic thread trimmer is available as an economical option, for cutthing ve thick sewing thread;
Excellent stitch pattern and constantly tight stitch formation due to its advanced pneumatic system, strong needle penetration force and custom made fixture;
Newbie friendly pattern making system, it is always a challenge for beginner to create new sewing pattern (design, program), we've got the perfect line-up of easy and beginner-friendly sewing patterns to allow a stress-free, and fun introduction to sewing;
Each machine supplies with comprehensive spare parts package that allow you to service, maintain and repair the machine for long time without the need to buy spare parts;
Over 20 years of combined experience in servicing and repairing, there is no problem that we cannot solve by email or video conference, that will insure your machine can be serviced with minimal downtime.

Specifications +

Max. Speed: 800 rpm
Max. sewing Area: 200x100mm
Max. Stitch Length: 12.7MM
Needle: 794 (DYx3) #26
Max.Thread Sizes:Metric #7, V415, T-400, 1300dx3
Bobbins: 7/8" x 1" large capacity
Maximum Foot Lift: 25mm
Max Sewn Thickness: 22mm
Pattern Input:Touch screen
Max. QTY of Patterns:2000 patterns
Air pressure: 0.6 MPa
Motor: 1000W/200-240 Volt
Packing size: 1200*1200*1400mm, G.W: 235KGS

Product Information +

Designed to meet the demands of today’s fast-paced manufacturing environment, adopts our extra-thick sewing technology accumulated over many years to a pattern sewing machine that differentiates itself with industry-leading needle penetration. The NEW HighTex extra heavy duty, automated pattern sewing machine can make a revolution in your sewing production of heavy duty safety harness and fall protection equipment. High quality maintains uniform stitches and strength even at high speed (1000 stit/min). Its automatic lower and upper hot knife thread trimmer is designed to cut extra thick thread. Bottom thread clamping device for a safe sewing start and for avoiding skip stitches at the seam beginning. Thread suction and clamping device for a neat seam (without bird nesting) beginning. Thread fraying is prevented by thread heat cutter, and can cut thread very short that eliminate manual thread trimming operations to improve productivity.
